8000 ISA+0°C -8 (2) 91.1 527 175 .35 220 22.8 32.3 37.0 41.8 46.5 51.3 60.8
-15°C -8 (1) 91.2 528 175 .35 221 22.8 32.3 37.0 41.8 46.5 51.2 60.7
ISA-10°C -17 (1) 93.8 597 195 .39 241 23.6 32.0 36.2 40.4 44.6 48.8 57.2
-25°C -17 92.7 574 190 .380 235 23.5 32.2 36.5 40.9 45.2 49.6 58.3
-18 91.6 553 185 .370 229 23.2 32.3 36.8 41.3 45.8 50.4 59.4
-18 90.6 533 180 .360 222 23.0 32.3 37.0 41.7 46.4 51.1 60.5
-19 (2) 89.5 513 175 .35 216 22.6 32.3 37.2 42.1 46.9 51.8 61.5
7500 ISA+0°C -8 (1) 91.2 528 178 .36 224 23.5 33.0 37.7 42.5 47.2 51.9 61.4
-15°C -8 90.6 517 175 .350 221 23.3 33.0 37.8 42.7 47.5 52.3 62.0
-9 (2) 89.8 503 171 .34 216 23.1 33.0 38.0 42.9 47.9 52.9 62.8
ISA-10°C -17 (1) 93.7 597 198 .39 244 24.0 32.4 36.6 40.8 45.0 49.2 57.5
-25°C -17 92.2 565 190 .380 235 23.9 32.7 37.1 41.6 46.0 50.4 59.3
-18 91.1 543 185 .370 229 23.7 32.9 37.5 42.1 46.7 51.3 60.5
-18 90.0 523 180 .360 222 23.4 33.0 37.8 42.5 47.3 52.1 61.7
-19 (2) 88.2 490 171 .34 212 22.8 33.0 38.1 43.2 48.3 53.4 63.6
7000 ISA+10°C 1 (1) 90.2 496 169 .34 217 23.6 33.7 38.7 43.8 48.8 53.9 63.9
-5°C 1 (2) 89.9 491 167 .33 215 23.5 33.7 38.8 43.9 49.0 54.0 64.2
ISA+0°C -8 (1) 91.1 527 180 .36 227 24.1 33.6 38.3 43.1 47.8 52.5 62.0
-15°C -8 90.0 506 175 .350 221 23.8 33.7 38.6 43.6 48.5 53.4 63.3
-9 88.9 487 170 .340 214 23.5 33.7 38.8 44.0 49.1 54.2 64.5
-9 (2) 88.3 478 167 .33 211 23.2 33.7 38.9 44.1 49.4 54.6 65.1
ISA-10°C -17 (1) 93.7 597 199 .40 246 24.4 32.8 37.0 41.1 45.3 49.5 57.9
-25°C -17 91.7 556 190 .380 235 24.3 33.2 37.7 42.2 46.7 51.2 60.2
-18 89.4 513 180 .360 222 23.9 33.6 38.5 43.4 48.2 53.1 62.8
-19 87.3 475 170 .340 210 23.2 33.7 39.0 44.3 49.5 54.8 65.3
-19 (2) 86.7 465 167 .33 207 22.9 33.7 39.1 44.4 49.8 55.2 65.9
6500 ISA+10°C 2 (1) 90.3 497 172 .34 221 24.3 34.4 39.4 44.4 49.5 54.5 64.6
-5°C 1 (2) 88.4 467 164 .33 210 23.7 34.4 39.7 45.1 50.4 55.8 66.5
ISA+0°C -8 (1) 91.1 527 182 .36 230 24.6 34.1 38.8 43.6 48.3 53.1 62.6
-15°C -8 89.4 497 175 .350 221 24.3 34.3 39.4 44.4 49.4 54.5 64.5
-9 88.3 477 170 .340 214 23.9 34.4 39.7 44.9 50.1 55.4 65.8
-9 (2) 86.8 455 164 .33 206 23.4 34.4 39.9 45.4 50.9 56.4 67.4
ISA-10°C -17 (1) 93.7 597 201 .40 248 24.7 33.1 37.3 41.5 45.6 49.8 58.2
-25°C -17 91.2 547 190 .380 235 24.6 33.8 38.3 42.9 47.5 52.0 61.2
-18 88.9 504 180 .360 222 24.3 34.2 39.2 44.1 49.1 54.1 64.0
-19 86.6 465 170 .340 210 23.7 34.4 39.8 45.2 50.6 55.9 66.7
-19 (2) 85.2 443 164 .33 202 23.1 34.4 40.0 45.7 51.3 57.0 68.2
51OM-00-01
(1) MAXIMUM CRUISE THRUST
(2) THRUST FOR MAXIMUM
RANGE (APPROXIMATE)
CITATION MUSTANG OPERATING MANUAL
510OM-00 41
CRUISE
17000 FEET
ANTI-ICE SYSTEMS OFF ONE ENGINE
FAN FUEL NAUTICAL MILES / 100 LBS FUEL
WT RAT PERCENT FLOW IND H E A D W I N D ZERO T A I L W I N D
LBS TEMP °C RPM LBS/HR KIAS MACH KTAS 100 KT 50 KT 25 KT WIND 25 KT 50 KT 100 KT
7500 ISA+0°C -12 (1) 91.8 506 173 .36 225 24.8 34.6 39.6 44.5 49.5 54.4 64.3
-19°C -12 (2) 91.2 496 170 .35 222 24.5 34.6 39.7 44.7 49.7 54.8 64.9
ISA-10°C -21 (1) 94.0 567 192 .40 244 25.4 34.2 38.6 43.0 47.4 51.8 60.7
-29°C -21 93.1 549 188 .390 239 25.3 34.4 39.0 43.5 48.1 52.6 61.7
-22 92.1 529 183 .380 233 25.1 34.6 39.3 44.0 48.7 53.5 62.9
-22 91.1 510 178 .370 227 24.9 34.7 39.6 44.5 49.4 54.3 64.1
-22 (2) 89.5 483 170 .35 217 24.3 34.6 39.8 45.0 50.2 55.4 65.7
7000 ISA+0°C -12 (1) 91.7 505 176 .37 229 25.5 35.4 40.3 45.3 50.2 55.1 65.0
-19°C -12 91.1 495 173 .360 225 25.3 35.4 40.4 45.5 50.5 55.6 65.7
-13 (2) 89.6 470 166 .35 216 24.7 35.4 40.7 46.0 51.3 56.6 67.3
ISA-10°C -21 (1) 94.0 567 194 .40 247 25.8 34.6 39.1 43.5 47.9 52.3 61.1
-29°C -21 92.6 540 188 .390 239 25.7 35.0 39.6 44.3 48.9 53.5 62.8
-22 91.6 519 183 .380 233 25.6 35.2 40.0 44.8 49.6 54.5 64.1
-22 90.5 500 178 .370 227 25.4 35.3 40.3 45.3 50.3 55.3 65.3
-23 (2) 87.9 458 166 .35 212 24.5 35.4 40.9 46.3 51.8 57.2 68.2
6500 ISA+10°C -2 (1) 90.5 470 166 .35 220 25.5 36.2 41.5 46.8 52.1 57.4 68.0
-9°C -3 (2) 89.7 458 162 .34 215 25.2 36.1 41.6 47.1 52.5 58.0 68.9
ISA+0°C -12 (1) 91.6 505 178 .37 232 26.1 36.0 40.9 45.9 50.8 55.8 65.7
-19°C -12 90.4 485 173 .360 225 25.8 36.1 41.3 46.4 51.6 56.7 67.0
-12 89.4 467 168 .350 219 25.5 36.2 41.5 46.9 52.2 57.6 68.3
-13 (2) 88.1 446 162 .34 211 24.9 36.2 41.8 47.4 53.0 58.6 69.8
ISA-10°C -21 (1) 93.9 568 196 .41 249 26.2 35.0 39.4 43.8 48.2 52.6 61.4
-29°C -21 92.2 531 188 .390 239 26.2 35.6 40.3 45.0 49.7 54.4 63.8
-22 89.9 491 178 .370 227 25.8 36.0 41.1 46.2 51.3 56.4 66.6
-23 87.7 455 168 .350 215 25.2 36.2 41.7 47.2 52.7 58.2 69.2
　
