1.原材料:MATERIAL:
1.1 外殼Shell: Copper Alloy 銅C2680 / 鐵SPCC/不繡鋼SUS
1.2 端子Contact: Copper Alloy 黃銅C2680 / 磷銅C5191
1.3 塑膠Housing: UL94V-0 PBT/LCP/PA White/Black
2.電氣性能ELECTRICSPECIFICATION:
2.1 額定電壓Voltage Rating:30V DC
2.2 額定電流Current Rating: 1.5 A/Contact terminal
2.3 拔出力Unmating Force: 1.02 Kgf MIN
2.4 接觸阻抗Contact Resistance: 30 mΩ MAX.
